How is Ex Vivo Lung Perfusion for Lung Transplantation done

How is Ex Vivo Lung Perfusion for Lung Transplantation done
October 30 06:00 2024 Print This Article

Summary

Ex Vivo Lung Procedure is a kind of therapy that is beneficial to people who are suffering from end-stage lung disease leading up to lung failure. For such people, lung transplant is the only solution. However, cadaver donor lungs are always less in number than the people on a transplant waiting list. On top of that, it is difficult for physicians to assess the suitability of donor lungs for transplant as the lungs may have been damaged at the time of harvesting. So, Ex Vivo Lung Procedure is a therapy in which donor lungs are treated outside the body in a machine, and operated as if they were inside the body and carefully evaluated. Post evaluation, they are transplanted into the recipient. In this article, we will learn more.

Introduction to Lung failure

The lungs are vulnerable to a range of conditions, and one of them is lung failure. This is a progressive condition in which the lung function is failing gradually and will culminate in total failure one day. This is fatal to the person. Lung transplantation is the only treatment option for such persons. This will require lungs to be harvested from cadaver donors (dead individuals whose families are willing to donate the lungs) and implanted in the body. The prospective recipients are listed on a waitlist and will get the lungs as per their turn. Till such time the actual transplant happens, the donated lungs will be kept in a freezer, at sub-zero temperatures. They will be thawed just before transplant.

However, the process is not easy as it sounds. The dead person may have suffered brain death and may have been in ICU for a certain duration of time. Both these situations can cause some damage to the cadaver lungs at the time of harvesting. The extent of damage can vary. In some cases, the lungs may not be usable at all. While in some cases, the lungs are partially damaged, in which case, they cannot be transplanted right-away. Both these situations reduce the percentage of donated lungs that can be used for transplantation. This is an unfortunate outcome for both the donor’s family and the recipient on the waiting list. In many cases, it even results in the demise of the waitlisted person.

So since the 2000s, and more so since 2011, a procedure called Ex Vivo Lung Perfusion (EVLP) emerged and evolved as the perfect solution in such a scenario.

What is Ex Vivo Lung Perfusion?

Ex Vivo Lung Perfusion (EVLP) is a unique therapy that is performed on cadaver donor lungs outside of the body and before transplant in the recipient’s body. This therapy improves the quality of the lungs and makes even those lungs that were previously unsuitable, safe for transplant now. This way, it expands or enlarges the donated lung pool for potential recipients of lung transplant.

EVLP was developed in the 2010s decade to address the issues of donated-lung wastages. Prior to EVLP, the donated lungs with whatever damage they possessed were kept in cold storage. When the transplant recipient was ready, the lungs were retrieved from cold storage, but many were not found to be suitable for transplant. So, EVLP takes a different approach.

In this case, the donor lungs are kept in a special machine at normal temperatures of 37 degrees Celsius. They are supplied with oxygen and other nutrients which helps them sustain, aerobic and active, cellular metabolism outside the body. This keeps them functioning as if they were inside a human body, for more than 12 hours. In the process, the lung function can be properly assessed. At the same time, the damage to the lungs is treated and healed. This is a boon to the lung-transplant recipient community, as it helps maximize the number of donor lungs that can be transplanted into waitlisted recipients.

To summarize, the EVLP is not just a therapy but a platform that helps:

  1. Evaluate the lung function outside the body
  2. Treat injuries in cadaver donor lungs
  3. Facilitate repair of cadaver donor lungs before transplantation

The EVLP Machine

The donated lungs are placed inside a sterile dome that is made of plastic fibre. The dome is attached to a ventilator, a pump and some filters. The temperature inside the sterile dome is maintained at normal body temperature of 37 degrees Celsius. The lungs are treated with a bloodless solution (called perfusate) that contains oxygen, proteins and nutrients. The solution helps reverse any injury in the lungs while also removing excess water from the lungs.

So, a typical EVLP circuit consists of

  • a centrifugal pump which pumps the perfusate solution through the….
  • …. membrane oxygenator and to a ….
  • leukocyte filter into the pulmonary artery
  • a standard ventilator that ventilates the lungs
  • a gas tank which is connected to the membrane oxygenator and consists of a mixture of nitrogen (86%), CO2 (8%), and O2 (6%)
  • a reservoir
  • left atrial (LA) cannula
  • and miscellaneous components

The Process

The EVLP process is highly technical is nature and describing it would require the use of highly techno-medical terminology, most of which are beyond the comprehension of people outside the medical community. That is why, we are giving a brief summary of each step after simplifying it as much as possible.

  • The first step would be to gather all the necessary equipment and supplies. This includes Steen Solution, the Perfadex solution in an ice cooler, bronchoscopy cart, drug box, slush machine, iSTAT machine for blood gases, XVIVO disposable kit and some cartridges.
  • Preparation of the organ chamber: A sterile nurse will open the outermost packaging of the organ chamber, lift it up, and place it on the back table. The outer cover of the organ chamber is opened aseptically while the organ chamber will remain covered in its innermost layer until the surgeons arrive.
  • The EVLP machine is turned on, and the perfusion circuit set up. The ventilator is connected in such a way that sweep gas and oxygen are connected to the equipment. A standard heater/cooler is set up, and three bottles of room temperature Steen Solution are added to the reservoir. Finally, the ventilator is calibrated and now, the system is ready for organ to be received.
  • Preparing the organ: The sterile nurse will uncover the organ chamber while the surgeon will remove the lungs from the organ bag in such a way that the innermost bag is intact.
  • Initiating retrograde flow: The Steen Solution is flushed through the lungs in a backward (retrograde) movement until the solution appears clear with no clots and debris in it.
  • Initiating anterograde flow: In this step, changes are made to the perfusate flow and temperature according to guidelines till the target temperature and flows are achieved.
  • Ventilation: Once the temperature of the Left Atrium effluent reaches 32 °F, ventilation is undertaken. A small sample of perfusate sample is drawn from the Left Atrium and Pulmonary Artery cannulas for analysis. A baseline chest X-ray is performed now.
  • Monitoring and maintenance: Steen Solution is added to the reservoir along with heparin, solumedrol and meropenem. Bronchoscopy is done as required, and a chest radiograph is taken before concluding the EVLP process to assess the impact on parenchymal opacities.
  • The transplant suitability is assessed using sets of inclusion and exclusion criteria.
  • Repackaging the lungs: Once the lungs reach 32 °F, the cannulas are disengaged from the circuit. A retrograde perfusion is done with 1 litre of Perfadex solution. After this and more steps, the lungs are again repacked in Perfadex solution.

Benefits

  • While previously, it was difficult for physicians to evaluate the donor lungs’ suitability for transplant, EVLP gives the same lungs a good chance at long-term success.
  • Since the lungs have undergone extensive evaluation and testing to determine their suitability, EVLP increases the likelihood that the recipient’s body will not reject the new lungs.
  • This way, the outcomes of EVLP-treated transplant procedures are better than those of traditional lung transplants.
  • And as mentioned before, EVLP expands the donor lung pool for recipients on the waiting list, which is a win-win for the recipient and donor families.
